Description
Power Supply (Voltage)
Single-Phase 230V/240V +/- 10%
Australian Standard
AS 60974.1:2020
Nominal Supply Frequency
50/60Hz
Supply Lead and Plug supplied
15 Amp
Minimum Single Phase Generator Recommendation
12kVA (at 0.8 Power Factor) at Max Amps
Amperage Range (MIG)
30 – 200A
Voltage Range (MIG)
15.5 – 24.0V
MIG (GMAW) Duty Cycle @ 40°C, 10 minutes
200 Amps @ 15%
100 Amps @ 60%
77 Amps @ 100%
STICK (MMAW) Duty Cycle @ 40°C, 10 minutes:
195 Amps @ 10%
80 Amps @ 60%
62 Amps @ 100%
TIG (GTAW) Duty Cycle @ 40°C, 10 minutes
200 Amps @ 15%
100 Amps @ 60%
77 Amps @ 100%
Nominal DC Open Circuit Voltage in MIG Mode
67V
Open Circuit Voltage (VRD On) STICK Mode
<35V
Weight of Power Source
13.4kg
Power Source Dimensions (mm)
L: 495 x W: 220 x H: 335
Weight of Full Package
21.7kg
Full Package Dimensions (mm)
L: 580 x W: 310 x H: 395
Protection Class
IP 21S
